Welcome to the AMD Vivado ChipScope Analyzer Hardware Debug for FPGA and Adaptive SoCs” tech module. Here's the agenda for this tech module. We will focus on ChipScope components, debug flows and ChipScoPy.After successfully implementing your design, the next step is to run it in hardware by programming the FPGA or adaptive SoC and debugging the design in-system. There are four main debug steps. They are probing, implementing, analyzing, and fixing.Probing. Identify the signals in your design that you want ...

This video takes a quick introductory look at the new ChipScoPy API. ...

This video walks through the installation process for the ChipScoPy API, including the official python install, obtaining the latest version of the ChipScoPy API and installing on a Windows PC. ...

This video demonstrates how to obtain the Hardware Server and ChipScope Server from the Unified Installer and how to connect ChipScoPy to the VCK190 evaluation platform. ...
