英特尔发布“2纳米级”工艺CPU,你的AI PC性能即将暴涨50%
量子位· 2025-10-10 01:03
梦晨 发自 凹非寺 量子位 | 公众号 QbitAI 英特尔 18A工艺 首秀,新一代酷睿Ultra处理器 Panther Lake 正式量产。 现在,靠工艺和架构设计的改进终于终结了这种尴尬的局面。 新架构CPU、图形、AI算力全面提升 Panther Lake整体架构延续并优化了自Meteor Lake以来的多芯粒(Chiplet)设计,将多个独立的功能模块(Tile)集成在单一封装上。 放弃了上一代部分产品把内存封装在处理器里的设计,给混乱的产品线开刀,打造了一个覆盖轻薄本到高性能游戏本的全能平台。 单看指标就足够亮眼:与前代产品相比 , CPU多核性能提升超过50%,图形性能提升超过50%,同时整体功耗降低30% 。 上代产品线中Lunar Lake走效率路线,特色是把内存封装在处理器里,这样电池续航确实给力,但价格也贵得离谱。 Arrow Lake走性能路线,还是使用外部内存,核心数量更多,但GPU架构比较老旧,AI算力也达不到微软Copilot+ PC的要求。 英特尔首席CPU架构师Stephen Robinson都反思:"上一代我们给用户出了道选择题。" Panther Lake主要由三个功能模 ...
英特尔18A正式亮相,两款芯片重磅发布
半导体行业观察· 2025-10-10 00:52
公众号记得加星标⭐️,第一时间看推送不会错过。 过去几个月,围绕着Intel18A和后续的芯片制造工艺有了很多的讨论,大家也对这家芯片巨头的未来 发展有了很多猜测。现在,随着基于这个工艺打造的Panther Lake(Core Ultra 3)和Clearwater Forest(Xeon 6+)的发布,很多的流言可以被打破。 九月底,半导体行业观察和一众国内媒体受邀去到英特尔位于亚利桑那凤凰城的工厂,了解并参观了 该公司位于当地的先进制造。在同期举办的Intel Tech Tour(简称ITT),英特尔技术人员还为我们 详细解读了Clearwater Forest和Panther Lake的设计和细节。 总而言之,在笔者看来,英特尔的这次如期量产给我们传递了一个信息:你大爷还是你大爷。 Intel 18A,两项黑科技 在介绍这两款芯片之前,我们先来了解一下英特尔备受关注,集成了两项黑科技的Intel 18A工艺。 按照英特尔所说,Intel 18A 工艺是美国开发和制造的首个 2 纳米级别节点,与Intel 35工艺相比, 每瓦性能提高了 15%,芯片密度提高了 30%。该节点在该公司位于俄勒冈州的工厂开发 ...
英特尔18A工艺首秀,Panther Lake深度揭秘:全新架构迎接AI浪潮
3 6 Ke· 2025-10-10 00:27
位于美国亚利桑那州的凤凰城,坐落着英特尔最先进的晶圆厂,而在9月份的最后几天,雷科技有幸被英特尔邀请参加其年度技术盛会ITT(Intel Technology Tour),飞越太平洋来到这座美丽的沙漠绿洲城市,参观并了解英特尔最新的技术成果。 图源:雷科技 在参观英特尔工厂的间隙,英特尔高级首席工程师Arik Gihon、英特尔院士Carlos Cordeiro、英特尔副总裁Chris Auth等人也为我们讲解了英特尔即将上市的 Panther Lake架构,剖开了其背后的技术秘密。 Panther Lake炸场,Intel 18A工艺首秀 Panther Lake是首个采用英特尔的Intel 18A工艺制造的消费级产品平台,作为英特尔目前最先进的量产制程,Intel 18A工艺具有两大全新特性:RibbonFET 环绕栅极晶体管和PowerVia背面供电。 图源:英特尔 其中,RibbonFET环绕栅极晶体管是英特尔为2nm及以下制程所准备的一项新技术,用新的晶体管架构取代了传统的FinFET架构,避免因工艺升级所带来 的漏电、性能不稳等问题。 对此不少朋友可能会有疑问:为什么工艺升级会导致漏电和性能不稳定 ...
英特尔18A良率已超越三星!
国芯网· 2025-07-15 13:57
Group 1 - The core viewpoint of the article highlights Intel's progress in its 18A process technology, with yield rates improving from 50% to 55%, surpassing Samsung's 2nm process yield of approximately 40% [1] - Although Intel's yield is still below TSMC's 2nm yield of 65%, it is expected to meet the conditions for high-volume manufacturing (HVM) by 2025, with potential yield improvements up to 70% [1] - The advancements in the 18A process will support the development of Intel's upcoming Panther Lake series and lay the groundwork for providing services to external customers in the future [2] Group 2 - Intel plans to transition to the 14A process after achieving success with the 18A process to further enhance its competitiveness in the high-end chip market [3]
英特尔芯片,又延期了?
半导体芯闻· 2025-03-05 10:25
Core Viewpoint - Intel's Panther Lake chips are likely to be delayed beyond 2025 due to slow yield improvements in the Intel 18A process, which may impact the company's revenue and profit in the second half of 2025 [1][2]. Group 1: Chip Production and Delays - Analyst Ming-Chi Kuo indicates that the production timeline for the Panther Lake (PTL) series has been pushed from early September 2025 to mid-Q4 2025, meaning devices using these chips may not be available until 2026 [1][2]. - Intel's initial production schedule communicated to partners was for the second half of 2025, but the delays could negatively affect the company's revenue, profit, and supply chain trust [2]. Group 2: Manufacturing Process Challenges - The Intel 18A manufacturing process, which utilizes RibbonFET and PowerVia technologies, has not achieved the expected yield rates, currently estimated at 20%-30%, hindering the company's ability to enter the shipping phase [2]. - Internal investigations suggest that there will be no improvement in yield rates by Q3, making it nearly impossible for Intel to achieve mass production within the anticipated timeline [2].
