Core Viewpoint - Semiconductor equipment company, Shengmei Shanghai, reported impressive performance in the first half of 2025, with significant revenue and profit growth driven by strong demand in the Chinese market and effective execution of its technology differentiation strategy [1][3][4]. Financial Performance - Shengmei Shanghai achieved operating revenue of 3.265 billion yuan, a year-on-year increase of 35.83% - The net profit attributable to shareholders reached 696 million yuan, up 56.99% year-on-year [1][3]. Market Demand and Strategy - The rapid growth in revenue and net profit is attributed to robust demand in the Chinese market, successful order accumulation, and efficient delivery and acceptance processes [3]. - The company has implemented a "product platformization" strategy, enhancing product technology and performance to meet diverse customer needs [3][4]. R&D Investment - In the first half of 2025, the company's R&D investment totaled 544 million yuan, a 39.47% increase year-on-year, representing 16.67% of operating revenue [5]. - The company has filed a total of 1,800 patents, with 494 granted, of which 489 are invention patents, indicating a strong focus on innovation [4][5]. Industry Position and Growth Potential - Shengmei Shanghai ranks fourth globally in semiconductor cleaning equipment with an 8.0% market share and third in semiconductor plating equipment with an 8.2% market share [7]. - The company is actively upgrading its products, including the Ultra C wb wet cleaning equipment, which utilizes patented nitrogen bubbling technology, enhancing its competitiveness in advanced chip manufacturing [7][8]. Future Outlook - The company anticipates full-year revenue for 2025 to be between 6.5 billion and 7.1 billion yuan, reflecting confidence in future growth based on industry trends and order forecasts [6]. - Shengmei Shanghai has developed a range of products, including cleaning, plating, and advanced packaging equipment, addressing a market potential of approximately 20 billion USD [9].

Core Insights - The demand for logic-to-memory integration driven by AI and high-performance computing is propelling advancements in panel-level packaging (PLP), with expectations that PLP will approach 10 times the maximum reticle size in the coming years [2][3] - Fan-out panel-level packaging (FOPLP) is emerging as a cost-effective solution, replacing silicon interposers with organic interposers, which is crucial for accommodating larger chip sizes and higher I/O counts [2][3][20] - The panel-level packaging market is projected to grow significantly, from $160 million in 2024 to $650 million, and nearly tripling to approximately $2.2 billion by 2030 [4] Panel-Level Packaging Developments - The integration of organic interposers and glass substrates is advancing, with companies like TSMC transitioning from wafer-based to panel-based processes for advanced packaging [3][4] - The choice of panel size varies based on application needs, with sizes ranging from 310 x 310 mm to 700 x 700 mm, influenced by existing manufacturing capabilities [5][6] - The utilization efficiency of panel-level packaging improves with larger interposer sizes, significantly reducing waste compared to wafer-level processes [6][10] Manufacturing Techniques and Challenges - Various manufacturing processes are being implemented in fan-out packaging, including chip-first, RDL-first, and mold-first methods, each with its own advantages and challenges [12][14] - Warpage remains a critical issue in fan-out packaging, exacerbated by differences in thermal expansion coefficients between materials, necessitating new materials and process controls to mitigate this risk [16][18][20] - Laser direct imaging and step-and-repeat lithography are both utilized for RDL patterning, with step-and-repeat lithography being more suitable for high throughput [10][20] Future Outlook - The future of panel-level packaging is promising, particularly for AI and HPC devices, as manufacturers seek to achieve yield rates comparable to current fan-out wafer-level packaging processes [20] - The development of new interlayer dielectric materials and molding materials with thermal expansion coefficients closer to silicon will enhance control over chip displacement and warpage [20]

Core Viewpoint - FOPLP (Fan-Out Panel Level Packaging) is gaining attention as an advanced packaging technology, with major competitors like TSMC, Powertech, and ASE adopting distinct names for their versions to differentiate in the market [1][2]. Group 1: FOPLP Technology Overview - FOPLP technology has been promoted by domestic packaging and testing companies for about 9 years, but significant end-user applications have been limited due to initial yield issues and a cautious client attitude [1]. - The technology's initial applications were primarily in RF IC and PMIC sectors, but there is a recent shift towards consumer electronics and AI applications, spurred by TSMC's leadership [1]. Group 2: Company Developments - Powertech has officially named its FOPLP technology PiFO, having achieved mass production as early as 2019, and claims to be the only company with large-scale FOPLP production capabilities [2]. - TSMC plans to establish its first CoPoS (Chip-on-Panel-on-Substrate) experimental line by 2026, with large-scale production expected between late 2028 and 2029, targeting NVIDIA as its first customer [2]. - ASE is utilizing the previously announced FoCoS name for its panel-level packaging technology, with a current production line for 300x300 panel-level packaging aimed at power management and automotive applications [2]. Group 3: Market Outlook - Industry experts believe that the focus of TSMC, Powertech, and ASE on high-end product applications in panel-level packaging will be crucial for the success of FOPLP technology [3]. - The future success of FOPLP as a next-generation advanced packaging solution will depend on resolving yield issues related to chip manufacturers' product positioning and warpage, as well as ensuring overall performance and cost-effectiveness for clients [3].

Group 1 - The core viewpoint is that FOPLP (Fan-Out Panel Level Packaging) technology is expected to see broader applications in advanced node packaging for AI, 5G, and high-performance computing by around 2027, driven by improvements in compatibility, standardization, warpage control, and uniformity in plating and etching processes [1] - FOPLP technology offers greater flexibility, scalability, and cost-effectiveness by integrating multiple chips, passive components, and interconnections within a single package, with the substrate evolving from circular wafers to square materials, currently reaching a maximum size of 700mm x 700mm, which is eight times the area of a 12-inch wafer [1] - The semiconductor equipment industry has been given an "overweight" rating due to the anticipated growth in FOPLP technology applications [1] Group 2 - The FOPLP technology faces challenges that require collaborative efforts across the industry chain, including initial equipment costs, limited supply chains, yield issues due to large format sizes, material compatibility, and the need for standardization [2] - Key technical challenges include precise warpage control and material consistency for high-density designs, integration of new dielectric materials, and maintaining uniformity in plating and etching processes [2] Group 3 - Domestic equipment companies are actively entering the panel-level packaging field, with notable products such as Chipbond's PLP 3000 direct-write lithography machine, which supports various substrates and offers advantages in RDL, UBM, and TSV processes [3] - Shengmei Shanghai has launched Ultra ECP ap-p panel-level plating equipment for RDL copper plating and circuit applications, while Changchuan Technology has also introduced related equipment for panel-level packaging [3]
